Intel Core i5-10300H vs Intel Core i5-10500H vs Intel Core i7-10750H

Intel Core i5-10300H

The Intel Core i5-10300H is a fast processor for laptops with four cores based on the Comet Lake-H series (4th generation of Skylake architecture). The processor clocks at between 2.5 and 4.5 GHz (up to 4.2 with 4 cores) and can execute up to eight threads simultaneously thanks to Hyper-Threading. According to Intel, the CPU is manufactured in 14nm (14nm++) process. Compared to the predecessor, the Core i5-9300H from 2019, the 10300H is clocked slightly higher (+100 MHz Base, +400 MHz Boost) and supports faster DDR4-2933 RAM.

The Comet Lake architecture is similar to Coffee Lake and offers the same features and is produced in the same 14nm process. Other than the improved clock rates, the memory controller now also supports faster DDR4-2933 RAM. More information on Comet Lake and all the models and articles on it can be found here.

The Core i5-10300H supports no vPro, TXT or SIPP. These business features are available in the faster Core i5-10400H (2.6 - 4.6 GHz) that was released at a later date.

Performance

The average 10300H in our database matches the AMD Ryzen 5 3550H in multi-thread performance. While not a poor result per se, it is indicative of an entry-level H-class CPU that is unlikely to meet the needs of hardcore gamers, professional videographers and similar clientele.

Your mileage may vary depending on how high the CPU power limits are and how competent the cooling solution of your system is.

Graphics

The integrated Intel UHD Graphics 630 iGPU is supposed to offer a similar performance as the UHD630 in the Core i5-9300H. As a low-end solution it will probably only run current games smoothly at reduced details - if at all.

Power consumption

The Core i5 has a default TDP (also known as the long-term power limit) of 45 W, a value that laptop makers are free to reduce slightly, 35 W being the lowest Intel-recommended value. Doing so would result in lower clock speeds and lower performance. Either way, a proper cooling solution is a must for a CPU like this.

The i5-10300H is manufactured on one of the old 14 nm Intel processes for lower-than-average, as of late 2022, energy efficiency.

Intel Core i5-10500H

The Intel Core i5-10500H is a fast processor for laptops with six cores based on the Comet Lake-H series (4th generation of Skylake architecture). The processor clocks at between 2.5 and 4.5 GHz and can execute up to twelve threads simultaneously thanks to Hyper-Threading. According to Intel, the CPU is manufactured on a 14nm (14nm++) process.

The Comet Lake architecture is similar to Coffee Lake and offers the same features and is produced on the same 14nm process. Other than the improved clock rates, the memory controller now also supports faster DDR4-2933 RAM. More information on Comet Lake and all the models and articles on it can be found here.

Performance

The average 10500H in our database matches the AMD Ryzen 7 4700U, a noticeably less power-hungry processor, in multi-thread performance making the i5 a somewhat underwhelming option as far as H-class processors go.

Your mileage may vary depending on how competent the cooling solution of your system is, and how high the CPU power limits are.

Graphics

The integrated Intel UHD Graphics 630 iGPU is supposed to offer a similar performance as the UHD630 in the Core i5-9300H. As a  low-end solution it will probably only run current games smoothly at reduced details - if at all.

Power consumption

This Core i5 series chip has a default TDP, also known as the long-term power limit, of 45 W. Laptop makers are free to reduce that value slightly, 35 W being the minimum Intel-recommended value, resulting in lower clock speed and lower performance. Either way, an active cooling solution will still be needed to dissipate the heat.

The i5-10500H is built with one of the old 14 nm Intel processes for low, as of mid 2023, energy efficiency.

Intel Core i7-10750H

The Intel Core i7-10750H is a fast 45 W processor designed for use in larger, beefier laptops. The Comet Lake-H family CPU was launched in mid-2020. It features six cores (twelve threads) running at 2.6 GHz Boosting up to 5 GHz (single-core Boost). The likely all-core Boost frequency is 4.3 GHz. Most of the specs are the same as the 10750H’s direct predecessor, the i7-9750H. The newer model has two advantages over its predecessor in that its Boost frequency is higher and the memory controller can now officially host memory clocked at 2,933 MHz, an upgrade over the 2,666 MHz limitation of the outgoing model.

Architecture

Comet Lake is a yet another revision of the dated Skylake architecture (not unlike the previous Coffee Lake, Whiskey Lake, Kaby Lake families) for similar feature set and performance-per-MHz figures. Core i7-10750H is manufactured on the third-gen 14 nm Intel process that is undeniably inferior to TSMC's 7 nm process, the one AMD’s Ryzen 4000 series laptop-grade processors are manufactured on.

The hexa-core CPU is compatible with up to 128 GB of dual-channel DDR4-2933 RAM and has support for PCI-Express 3.0 and Thunderbolt 3 but not the professional features (vPro, TXT, SIPP) as found in the case of Core i7-10850H.

Both the CPU cores and the iGPU have access to 12 MB of L3 cache. Four PCI-Express 3.0 lanes allow for read/write rates of up to 3.9 GB/s provided a suitably fast NVMe SSD is used.

The 10750H gets soldered permanently on to the motherboard (BGA1440 socket interface) and is thus pretty much impossible to replace.

Performance

Multi-thread performance is most similar to the Core i5-10500H, the Core i5-11400H and also the Ryzen 7 4700U. While perhaps not the best bang for the buck, the i7 is fast enough for any task, gaming included, as of late 2021.

Thanks to its decent cooling solution and a long-term CPU power limit of 75 W, the ThinkPad P15 Gen 1-20ST000DGE is among the fastest laptops built around the 10750H that we know of. It can be about 80% faster in CPU-bound workloads than the slowest system featuring the same chip in our database, as of August 2023.

Graphics

We've known the Intel UHD Graphics 630 iGPU for a while. This is the same iGPU the Core i7-9750H and Core i7-8750H processors had. In this i7, the 24 EU iGPU is clocked at 350 MHz to 1,150 MHz.

Intel UHD Graphics 630 will let you connect up to 3 monitors with resolutions of up to 4096x2304@60. The built-in video decoder will happily handle AVC, HEVC, VP9 and other popular video codecs (AV1 is not supported though). This is not a gaming GPU as it is not fast enough to handle most AAA titles released in 2020. At 720p, Escape from Tarkov runs at just 17 fps (low quality preset), to give you an example. As the iGPU has no VRAM of its own, it is paramount that it is mated to fast system RAM.

Power consumption

This Core i7 series chip is built with one of the old 14 nm Intel processes leading to subpar, as of early 2022, energy efficiency.

The Core i7-10750H has a default TDP, also known as the long-term power limit, of 45 W; laptop makers are free to reduce the value somewhat, 35 W being the lower limit, allowing for leaner designs at the cost of performance. Either way, a quality cooling solution is a must.
