AMD Radeon R7 M460 vs AMD Radeon R7 M445
AMD Radeon R7 M460
► remove from comparison
The AMD Radeon R7 M460 is an entry level graphics card for laptops. It was announced in the Lenovo Yoga 510 (15-inch-model) in early 2016. The technical details are more or less identical to the older Radeon R7 M360 (see for benchmarks). Only the core speed was increased slightly by 8 MHz in our test sample.
AMD Radeon R7 M445
► remove from comparisonThe Radeon R7 M445 is an entry-level graphics card for laptops. It is based on the same chip as the old Radeon R7 M340 (and therefore renamed M440) but features faster GDDR5 graphics memory. Although the core speed is slightly reduced, compared to the M440, the general performance is clearly better. On average the gaming performance should be similar to a Nvidia GeForce 940M (or 940MX with DDR3).
The Radeon R7 M445 is produced in 28 nm and still based on an old GCN chip (no new Polaris architecture).
| AMD Radeon R7 M460 | AMD Radeon R7 M445 | |||||||||||||||||||
| Radeon R7 M400 Series |
|
| ||||||||||||||||||
| Architecture | GCN | GCN | ||||||||||||||||||
| Pipelines | 384 - unified | 320 - unified | ||||||||||||||||||
| Core Speed | 984 MHz | 920 MHz | ||||||||||||||||||
| Memory Speed | 2000 MHz | 2000 MHz | ||||||||||||||||||
| Memory Bus Width | 64 Bit | 64 Bit | ||||||||||||||||||
| Shared Memory | no | no | ||||||||||||||||||
| API | DirectX 12, OpenGL 4.3 | DirectX 12, Shader 5.0, OpenGL 4.5 | ||||||||||||||||||
| technology | 28 nm | 28 nm | ||||||||||||||||||
| Features | DirectX 12, Mantle, OpenGL 4.3, OpenCL 1.2, Vulkan | DirectX 12, Mantle, OpenGL, OpenCL 1.2, Vulkan | ||||||||||||||||||
| Date of Announcement | 21.02.2016 | 15.05.2016 | ||||||||||||||||||
| Memory Type | GDDR5 | |||||||||||||||||||
| Max. Amount of Memory | 4 GB | |||||||||||||||||||
| Power Consumption | 15-25 Watt | |||||||||||||||||||
| Link to Manufacturer Page | www.amd.com |
Benchmarks
3DM Vant. Perf. total + AMD Radeon R7 M460
Cinebench R15 OpenGL 64 Bit + AMD Radeon R7 M460
GFXBench T-Rex HD Offscreen C24Z16 + AMD Radeon R7 M460
Average Benchmarks AMD Radeon R7 M460 → 100% n=16
Average Benchmarks AMD Radeon R7 M445 → 125% n=16
- Average benchmark values for this graphics card* Smaller numbers mean a higher performance
1 This benchmark is not used for the average calculation
Game Benchmarks
The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.
Resident Evil 7
2017
Watch Dogs 2
2016
Dishonored 2
2016
Titanfall 2
2016
Farming Simulator 17
2016
Battlefield 1
2016
Mafia 3
2016
FIFA 17
2016
No Man's Sky
2016
Overwatch
2016
Doom
2016
Need for Speed 2016
2016
Hitman 2016
2016
The Division
2016
Far Cry Primal
2016
XCOM 2
2016
Rainbow Six Siege
2015
Just Cause 3
2015
Fallout 4
2015
Anno 2205
2015
FIFA 16
2015
World of Warships
2015
Metal Gear Solid V
2015
The Witcher 3
2015
Dirt Rally
2015
GTA V
2015
F1 2014
2014
Alien: Isolation
2014
Sims 4
2014
GRID: Autosport
2014
Battlefield 4
2013
Metro: Last Light
2013
BioShock Infinite
2013
Tomb Raider
2013
Crysis 3
2013
Diablo III
2012Average Gaming AMD Radeon R7 M460 → 100%
Average Gaming 30-70 fps → 100%
Average Gaming AMD Radeon R7 M445 → 123%
Average Gaming 30-70 fps → 116%
| AMD Radeon R7 M460 | AMD Radeon R7 M445 | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| low | med. | high | ultra | QHD | 4K | low | med. | high | ultra | QHD | 4K | |||
| Resident Evil 7 | 55.3 | 24.1 | 13.9 | |||||||||||
| Watch Dogs 2 | 30.2 | 24.1 | 11.5 | |||||||||||
| Dishonored 2 | 23.4 | 18.6 | 12.2 | 9.9 | ||||||||||
| Call of Duty Infinite Warfare | 29.1 | 26.1 | 14.7 | 27 | 24 | 16 | ||||||||
| Titanfall 2 | 40.8 | 30.6 | 12.5 | 57 | 41 | 17 | 16 | |||||||
| Farming Simulator 17 | 95.8 | 62.6 | 24 | 10 | 64.2 | 42.9 | 16.9 | 10 | ||||||
| Battlefield 1 | 30 | 20.6 | 10.1 | 40 | 28 | 13 | 12 | |||||||
| FIFA 17 | 83.8 | 70.3 | 36.1 | 34.1 | 61.8 | 59.7 | 34.6 | 29.4 | ||||||
| Deus Ex Mankind Divided | 14.5 | 10.6 | 5.4 | 21 | 14 | 7 | ||||||||
| Overwatch | 75.3 | 52.6 | 23.5 | 14.1 | ||||||||||
| Doom | 23.3 | 13.3 | 7.9 | 35 | 28 | 14 | ||||||||
| The Division | 29.9 | 16.3 | 7.2 | 32.4 | 24.5 | 9.6 | 6.7 | |||||||
| Far Cry Primal | 22 | 10 | 8 | 7 | 27 | 12 | 10 | |||||||
| XCOM 2 | 22.5 | 7.8 | 5.2 | 22.8 | 7.9 | 5.2 | 4.9 | |||||||
| Rise of the Tomb Raider | 19.5 | 12.2 | 6.8 | 29.6 | 15.1 | 8.5 | 6.7 | |||||||
| Rainbow Six Siege | 51.9 | 31.8 | 13.1 | 10.6 | 64.4 | 37.8 | 20.1 | 13.5 | ||||||
| The Witcher 3 | 20.7 | 13.4 | 6.7 | 30.8 | 18.2 | 9.6 | 4.7 | |||||||
| GTA V | 50.5 | 45.2 | 10.7 | 50.7 | 43.7 | 12.2 | ||||||||
| Sims 4 | 137.5 | 49.9 | 21.7 | 18.6 | 132.9 | 66.9 | 28.8 | 27.4 | ||||||
| Battlefield 4 | 59.4 | 38 | 23.9 | 7.8 | 74.3 | 49.6 | 32.7 | 11.7 | ||||||
| BioShock Infinite | 73 | 40 | 32 | 10 | 98.7 | 53.9 | 44.5 | 13.8 | ||||||
| AMD Radeon R7 M460 | AMD Radeon R7 M445 | |||||||||||||
| low | med. | high | ultra | QHD | 4K | low | med. | high | ultra | QHD | 4K | < 30 fps < 60 fps < 120 fps ≥ 120 fps | 8 5 3 1 | 9 6 2 | 15 2 | 6 1 | | | < 30 fps < 60 fps < 120 fps ≥ 120 fps | 6 8 6 1 | 12 8 1 | 18 3 | 14 | | |
For more games that might be playable and a list of all games and graphics cards visit our Gaming List
