AMD Radeon HD 6730M vs AMD Radeon HD 6630M vs AMD Radeon HD 6770M

AMD Radeon HD 6730M

► remove from comparison AMD Radeon HD 6730M

  The AMD Radeon HD 6730M (sometimes also called ATI Mobility Radeon HD 6730 or similar) is a fast middle class graphics card for laptops. It supports DirectX11, is the successor of the HD 5730, and features higher clock rates, 80 more shaders, Eyefinity+ and the new UVD3 video decoder. However, it is still produced in 40nm and based on the same Whister chip as the whole 6700M and 6600M series. First informations also suggest, that the HD 6730M is a 6770M with slow DDR3 memory.

The 480 Stream processors should be still based on the "old" 5D architecture similar to the 5000 series. Therefore, the number of shaders is not comparable to the 1D cores of current Nvidia GPUs. The Tessellation performance should be improved (like the desktop 6800 series) with the new cards. The Stream processors can be used with DirectX 11, OpenGL 4.1, DirectCompute 11 and OpenCL. With the later two the cores can also be used for general computations like transcoding videos.

The 3D performance should be a bit above the old Radeon HD 5730 due to the larger amount of shaders. Therefore, current and demanding games should run fluently in 1366x768 and medium to high details. Less demanding games like Sims 3 or Fifa 11 should run in high details and resolutions.

The new UVD3 video decoder supports the decoding of MPEG-4 AVC/H.264, VC-1, MPEG-2, Flash and now also Multi-View Codec (MVC) and MPEG-4 part 2 (DivX, xVid) HD videos on the graphics card.

Furthermore, the HD 6700M series integrates a HD audio controller to transmit HD Audio (TrueHD or DTS Master Audio) over HDMI and DisplayPort (e.g. for Blu-Ray videos).

The AMD HD3D Technology offers support for Blu-Ray 3D and 3D displays (integrated and external). However, the solution is not as mature as Nvidias 3D Vision.

Thanks to Eyefinity the graphics chip is able to theoretically drive up to 5 monitors simultaneously. However, this only works if the laptop features enough DisplayPort outputs.

The power consumption of the chip should be similar to the Mobility Radeon HD 5730 and therefore suited for 15" laptops and up.

AMD Radeon HD 6630M

► remove from comparison AMD Radeon HD 6630M

The AMD Radeon HD 6630M (sometimes also called ATI Mobility Radeon HD 6630 or similar) is a  middle class graphics card for laptops. It supports DirectX11 and is the successor of the low clocked HD 5650 chips (low power). Compared to the HD 5650 it offers 80 more shader, Eyefinity+ and the new UVD3 video decoder.

The 480 Stream processors should be still based on the "old" 5D architecture similar to the 5000 series. Therefore, the number of shaders is not comparable to the 1D cores of current Nvidia GPUs. The Tessellation performance should be improved (like the desktop 6800 series) with the new cards. The Stream processors can be used with DirectX 11, OpenGL 4.1, DirectCompute 11 and OpenCL. With the later two the cores can also be used for general computations like transcoding videos.

The 3D performance should is similar to the older Radeon HD 5650 due to the larger amount of shaders. Therefore, current and demanding games should run fluently in 1366x768 and medium to high details. Less demanding games like Sims 3 or Fifa 11 should run in high details and resolutions. Detailed gaming benchmarks can be found below.

The new UVD3 video decoder supports the decoding of MPEG-4 AVC/H.264, VC-1, MPEG-2, Flash and now also Multi-View Codec (MVC) and MPEG-4 part 2 (DivX, xVid) HD videos on the graphics card.

Furthermore, the HD 6600M series integrates a HD audio controller to transmit HD Audio (TrueHD or DTS Master Audio) over HDMI and DisplayPort (e.g. for Blu-Ray videos).

The AMD HD3D Technology offers support for Blu-Ray 3D and 3D displays (integrated and external). However, the solution is not as mature as Nvidias 3D Vision.

Thanks to Eyefinity the graphics chip is able to theoretically drive up to 5 monitors simultaneously. However, this only works if the laptop features enough DisplayPort outputs.

The power consumption of the chip should be similar to the low clocked Mobility Radeon HD 5650 chips and therefore suited for 14" laptops and up.

AMD Radeon HD 6770M

► remove from comparison AMD Radeon HD 6770M

The AMD Radeon HD 6770M (sometimes also called ATI Mobility Radeon HD 6770 or similar) is a fast middle class graphics card for laptops in 2011. It supports DirectX11, is the successor of the HD 5770, and features higher clock rates, 80 more shaders, Eyefinity+ and the new UVD3 video decoder. However, it is still produced in 40nm and based on the same Whistler chip as the entire 6700M and 6600M series. The chip is normally clocked at 725 MHz, but is only clocked at 675 MHz in the MacBook Pro 15 Late 2011 model.

The 480 Stream processors should still based on the "old" 5D architecture similar to the 5000 series. Therefore, the number of shaders is not comparable to the 1D cores of current Nvidia GPUs. The Tessellation performance, however, should be an improvement with the new cards. The Stream processors can be used with DirectX 11, OpenGL 4.1, DirectCompute 11 and OpenCL. The latter two APIs can exploit the GPU for general computations like transcoding videos.

The 3D performance of the 6770M is slightly better than the GeForce GT 555M and is therefore positioned in the upper middle class as of 2011. Demanding games like Anno 2070 or Skyrim can only be played in medium detail settings and lower resolutions. Certain games, such as Battlefield 3, may even only run in low detail settings. Older games like Call of Duty: Black Ops are playable with all settings maxed.

The new UVD3 video decoder supports the decoding of MPEG-4 AVC/H.264, VC-1, MPEG-2, Flash and now also Multi-View Codec (MVC) and MPEG-4 part 2 (DivX, xVid) HD videos on the graphics card.

Furthermore, the HD 6700M series integrates an HD audio controller to transmit HD Audio (TrueHD or DTS Master Audio) over HDMI and DisplayPort (e.g., for Blu-Ray videos).

The AMD HD3D Technology offers support for Blu-Ray 3D and 3D displays (integrated and external). However, the solution is not as mature as 3D Vision from Nvidia in terms of dirvers and overall support.

Thanks to Eyefinity, the AMD card is able to theoretically drive up to 5 monitors simultaneously. This would only work, however, if the laptop features enough DisplayPort outputs.

The power consumption of the 6770M should be similar to the Mobility Radeon HD 5770. As a result, the 6770M is normally only found in 15-inch or larger notebooks.

show full text
AMD Radeon HD 6730MAMD Radeon HD 6630MAMD Radeon HD 6770M
Radeon HD 6600M/6700M Series
Radeon HD 6770M 480 @ 0.68 GHz128 Bit @ 800 MHz
Radeon HD 6750M 480 @ 0.6 GHz128 Bit @ 900 MHz
Radeon HD 6730M 480 @ 0.73 GHz128 Bit @ 800 MHz
Radeon HD 6650M 480 @ 0.6 GHz128 Bit @ 900 MHz
Radeon HD 6630M 480 @ 0.49 GHz128 Bit @ 800 MHz
Radeon HD 6770M 480 @ 0.68 GHz128 Bit @ 800 MHz
Radeon HD 6750M 480 @ 0.6 GHz128 Bit @ 900 MHz
Radeon HD 6730M 480 @ 0.73 GHz128 Bit @ 800 MHz
Radeon HD 6650M 480 @ 0.6 GHz128 Bit @ 900 MHz
Radeon HD 6630M 480 @ 0.49 GHz128 Bit @ 800 MHz
Radeon HD 6770M 480 @ 0.68 GHz128 Bit @ 800 MHz
Radeon HD 6750M 480 @ 0.6 GHz128 Bit @ 900 MHz
Radeon HD 6730M 480 @ 0.73 GHz128 Bit @ 800 MHz
Radeon HD 6650M 480 @ 0.6 GHz128 Bit @ 900 MHz
Radeon HD 6630M 480 @ 0.49 GHz128 Bit @ 800 MHz
CodenameWhistler-XTWhistler-LPWhistler-XT
ArchitectureTerascale 2Terascale 2Terascale 2
Pipelines480 - unified480 - unified480 - unified
Core Speed725 MHz485 MHz675 / 725 MHz
Memory Speed800 MHz800 MHz800 MHz
Memory Bus Width128 Bit128 Bit128 Bit
Memory TypeDDR3DDR3GDDR5
Shared Memorynonono
APIDirectX 11, Shader 5.0DirectX 11, Shader 5.0DirectX 11, Shader 5.0, OpenGL 4.0
technology40 nm40 nm40 nm
Notebook Sizemedium sizedmedium sizedmedium sized
Date of Announcement04.01.2011 04.01.2011 04.01.2011
Link to Manufacturer Pagewww.amd.comwww.amd.comwww.amd.com
Transistors716 Million

Benchmarks

3DMark 11 - 3DM11 Performance Score
1269 Points (2%)
min: 968     avg: 1000     median: 990 (1%)     max: 1050 Points
min: 1347     avg: 1475     median: 1475.5 (2%)     max: 1561 Points
3DMark 11 - 3DM11 Performance GPU
1141 Points (1%)
min: 861     avg: 887     median: 877 (1%)     max: 927 Points
min: 1271     avg: 1328     median: 1328 (1%)     max: 1379 Points
3DMark Vantage
3DM Vant. Perf. total + AMD Radeon HD 6730M
3DMark Vantage - 3DM Vant. Perf. total
4438 Points (1%)
3DM Vant. Perf. total + AMD Radeon HD 6630M
min: 3184     avg: 3757     median: 3720 (1%)     max: 4224 Points
3DM Vant. Perf. total + AMD Radeon HD 6770M
min: 5531     avg: 6072     median: 6106.5 (2%)     max: 6495 Points
3DM Vant. Perf. GPU no PhysX + AMD Radeon HD 6730M
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
3752 Points (2%)
3DM Vant. Perf. GPU no PhysX + AMD Radeon HD 6630M
min: 3041     avg: 3194     median: 3128 (2%)     max: 3512 Points
3DM Vant. Perf. GPU no PhysX + AMD Radeon HD 6770M
min: 4899     avg: 5150     median: 5159 (3%)     max: 5369 Points
3DMark 2001SE - 3DMark 2001 - Standard
47877 Points (50%)
3DMark 03 - 3DMark 03 - Standard
23075 Points (12%)
min: 12392     avg: 16867     median: 16385 (9%)     max: 20557 Points
min: 19530     avg: 24325     median: 24012 (13%)     max: 29744 Points
3DMark 05 - 3DMark 05 - Standard
15492 Points (17%)
min: 11187     avg: 12640     median: 12528 (14%)     max: 13513 Points
min: 9017     avg: 15484     median: 16773.5 (18%)     max: 19373 Points
3DMark 06 3DMark 06 - Standard 1280x1024 + AMD Radeon HD 6730M
3DMark 06
7918 Points (10%)
3DMark 06 - Standard 1280x1024 + AMD Radeon HD 6630M
min: 6432     avg: 6858     median: 6934 (9%)     max: 7269 Points
3DMark 06 - Standard 1280x1024 + AMD Radeon HD 6770M
min: 9266     avg: 10127     median: 10056 (13%)     max: 10762 Points
3DMark 06 - Score Unknown Settings + AMD Radeon HD 6630M
3DMark 06
min: 6446     avg: 6978     median: 6978 (9%)     max: 7510 Points
3DMark 06 - Score Unknown Settings + AMD Radeon HD 6770M
10992 Points (14%)
3DMark 06 - Standard 1280x768 + AMD Radeon HD 6630M
3DMark 06
7321 Points (10%)
Unigine Heaven 2.1 - Heaven 2.1 high
12.6 fps (2%)
min: 10.3     avg: 10.6     median: 10.7 (2%)     max: 10.9 fps
min: 16.1     avg: 16.5     median: 16.5 (3%)     max: 16.9 fps
SPECviewperf 11
specvp11 snx-01 + AMD Radeon HD 6730M
SPECviewperf 11 - specvp11 snx-01
6.8 fps (4%)
specvp11 snx-01 + AMD Radeon HD 6630M
min: 0.28     avg: 2.8     median: 2.8 (2%)     max: 5.29 fps
specvp11 snx-01 + AMD Radeon HD 6770M
7.1 fps (4%)
specvp11 tcvis-02 + AMD Radeon HD 6730M
SPECviewperf 11 - specvp11 tcvis-02
5 fps (3%)
specvp11 tcvis-02 + AMD Radeon HD 6630M
min: 0.17     avg: 2.3     median: 2.3 (1%)     max: 4.43 fps
specvp11 tcvis-02 + AMD Radeon HD 6770M
4.8 fps (3%)
specvp11 sw-02 + AMD Radeon HD 6730M
SPECviewperf 11 - specvp11 sw-02
18.7 fps (14%)
specvp11 sw-02 + AMD Radeon HD 6630M
16.3 fps (12%)
specvp11 sw-02 + AMD Radeon HD 6770M
19.3 fps (15%)
specvp11 proe-05 + AMD Radeon HD 6730M
SPECviewperf 11 - specvp11 proe-05
2.2 fps (3%)
specvp11 proe-05 + AMD Radeon HD 6630M
min: 0.67     avg: 1.1     median: 1.1 (1%)     max: 1.57 fps
specvp11 proe-05 + AMD Radeon HD 6770M
2 fps (2%)
specvp11 maya-03 + AMD Radeon HD 6730M
SPECviewperf 11 - specvp11 maya-03
10.7 fps (8%)
specvp11 maya-03 + AMD Radeon HD 6630M
8.7 fps (7%)
specvp11 maya-03 + AMD Radeon HD 6770M
8.6 fps (6%)
specvp11 lightwave-01 + AMD Radeon HD 6730M
SPECviewperf 11 - specvp11 lightwave-01
24.3 fps (26%)
specvp11 lightwave-01 + AMD Radeon HD 6630M
19.2 fps (21%)
specvp11 lightwave-01 + AMD Radeon HD 6770M
23 fps (25%)
specvp11 ensight-04 + AMD Radeon HD 6730M
SPECviewperf 11 - specvp11 ensight-04
13.2 fps (6%)
specvp11 ensight-04 + AMD Radeon HD 6630M
min: 0.18     avg: 6.1     median: 6.1 (3%)     max: 12.11 fps
specvp11 ensight-04 + AMD Radeon HD 6770M
14.7 fps (7%)
specvp11 catia-03 + AMD Radeon HD 6730M
SPECviewperf 11 - specvp11 catia-03
6.2 fps (3%)
specvp11 catia-03 + AMD Radeon HD 6630M
5 fps (3%)
specvp11 catia-03 + AMD Radeon HD 6770M
5.9 fps (3%)
Windows 7 Experience Index - Win7 Gaming graphics
6.8 Points (86%)
min: 6.4     avg: 6.6     median: 6.7 (85%)     max: 6.7 Points
min: 6.6     avg: 6.8     median: 6.9 (87%)     max: 6.9 Points
Windows 7 Experience Index - Win7 Graphics
6.8 Points (86%)
min: 4.7     avg: 6     median: 6.7 (85%)     max: 6.7 Points
min: 6.6     avg: 6.8     median: 6.9 (87%)     max: 6.9 Points
Cinebench R10 Cinebench R10 Shading (32bit) + AMD Radeon HD 6730M
Cinebench R10 - Cinebench R10 Shading (32bit)
7282 Points (5%)
Cinebench R10 Shading (32bit) + AMD Radeon HD 6630M
min: 4151     avg: 6049     median: 5952 (4%)     max: 8165 Points
Cinebench R10 Shading (32bit) + AMD Radeon HD 6770M
min: 5545     avg: 6818     median: 6907.5 (5%)     max: 8508 Points
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit + AMD Radeon HD 6730M
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
37 fps (12%)
Cinebench R11.5 OpenGL 64 Bit + AMD Radeon HD 6630M
min: 7.98     avg: 21.4     median: 30.5 (10%)     max: 31.73 fps
Cinebench R11.5 OpenGL 64 Bit + AMD Radeon HD 6770M
min: 47.87     avg: 48.2     median: 48 (16%)     max: 48.7 fps

Average Benchmarks AMD Radeon HD 6730M → 100% n=20

Average Benchmarks AMD Radeon HD 6630M → 76% n=20

Average Benchmarks AMD Radeon HD 6770M → 109% n=20

- Range of benchmark values for this graphics card
red legend - Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
1 This benchmark is not used for the average calculation

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

Risen 2: Dark Waters

Risen 2: Dark Waters

2012
low 1024x768
Radeon HD 6630M:
33  fps
med. 1366x768
Radeon HD 6630M:
21  fps
high 1366x768
Radeon HD 6630M:
16  fps
ultra 1920x1080
Radeon HD 6630M:
8  fps
Mass Effect 3

Mass Effect 3

2012
low 1280x720
Radeon HD 6630M:
43  fps
high 1366x768
Radeon HD 6630M:
38  fps
ultra 1920x1080
Radeon HD 6630M:
18  fps
Star Wars: The Old Republic

Star Wars: The Old Republic

2011
low 1024x768
Radeon HD 6770M:
69.2  fps
high 1366x768
Radeon HD 6770M:
39.8  fps
Anno 2070

Anno 2070

2011
low 1024x768
Radeon HD 6630M:
74  fps
Radeon HD 6770M:
95 105 ~ 100 fps
med. 1366x768
Radeon HD 6630M:
28  fps
Radeon HD 6770M:
40 42 ~ 41 fps
high 1366x768
Radeon HD 6630M:
18  fps
Radeon HD 6770M:
26.3 27 ~ 27 fps
ultra 1920x1080
Radeon HD 6630M:
10  fps
Radeon HD 6770M:
13.5 15 ~ 14 fps
The Elder Scrolls V: Skyrim

The Elder Scrolls V: Skyrim

2011
low 1280x720
Radeon HD 6630M:
42 58.9 ~ 50 fps
Radeon HD 6770M:
59  fps
med. 1366x768
Radeon HD 6630M:
29 35.8 ~ 32 fps
Radeon HD 6770M:
39.8 43 ~ 41 fps
high 1366x768
Radeon HD 6630M:
19 20.1 ~ 20 fps
Radeon HD 6770M:
29 30.4 ~ 30 fps
ultra 1920x1080
Radeon HD 6630M:
10  fps
Radeon HD 6770M:
15 15 ~ 15 fps
CoD: Modern Warfare 3

CoD: Modern Warfare 3

2011
low 1024x768
Radeon HD 6630M:
155  fps
med. 1366x768
Radeon HD 6630M:
64  fps
high 1366x768
Radeon HD 6630M:
38  fps
ultra 1920x1080
Radeon HD 6630M:
20  fps
Battlefield 3

Battlefield 3

2011
low 1024x768
Radeon HD 6630M:
28 40.6 ~ 34 fps
Radeon HD 6770M:
37.7 39 ~ 38 fps
med. 1366x768
Radeon HD 6630M:
19 25.2 ~ 22 fps
Radeon HD 6770M:
26.7 28 ~ 27 fps
high 1366x768
Radeon HD 6630M:
16 23.5 ~ 20 fps
Radeon HD 6770M:
21.1 22 ~ 22 fps
Batman: Arkham City

Batman: Arkham City

2011
low 1024x768
Radeon HD 6770M:
77  fps
med. 1366x768
Radeon HD 6770M:
58  fps
high 1366x768
Radeon HD 6770M:
18  fps
ultra 1920x1080
Radeon HD 6770M:
8  fps
Fifa 12

Fifa 12

2011
low 800x600
Radeon HD 6770M:
297.1  fps
med. 1024x768
Radeon HD 6770M:
150.8  fps
high 1360x768
Radeon HD 6630M:
66  fps
Radeon HD 6770M:
93.7  fps
ultra 1920x1080
Radeon HD 6630M:
35  fps
Radeon HD 6770M:
50 53.6 ~ 52 fps
F1 2011

F1 2011

2011
low 800x600
Radeon HD 6630M:
59  fps
Radeon HD 6770M:
105  fps
med. 1024x768
Radeon HD 6630M:
37  fps
Radeon HD 6770M:
67  fps
high 1366x768
Radeon HD 6630M:
20  fps
Radeon HD 6770M:
36  fps
ultra 1920x1080
Radeon HD 6630M:
13  fps
Radeon HD 6770M:
17 20 ~ 19 fps
Deus Ex Human Revolution

Deus Ex Human Revolution

2011
low 1024x768
Radeon HD 6630M:
66.7 94 ~ 80 fps
Radeon HD 6770M:
125  fps
high 1366x768
Radeon HD 6630M:
31 31.3 35.9 ~ 33 fps
Radeon HD 6770M:
42 42.1 ~ 42 fps
ultra 1920x1080
Radeon HD 6630M:
14 14 ~ 14 fps
Radeon HD 6770M:
18.9 19 ~ 19 fps
Dirt 3

Dirt 3

2011
low 800x600
100%
Radeon HD 6730M:
134.8  fps
73%
Radeon HD 6630M:
78 89.5 127 ~ 98 fps
62%
Radeon HD 6770M:
83.2  fps
med. 1024x768
100%
Radeon HD 6730M:
62.9  fps
107%
Radeon HD 6630M:
47 51.4 103 ~ 67 fps
86%
Radeon HD 6770M:
54  fps
high 1360x768
100%
Radeon HD 6730M:
41.6  fps
91%
Radeon HD 6630M:
35 36.3 42 ~ 38 fps
111%
Radeon HD 6770M:
46.3  fps
ultra 1920x1080
100%
Radeon HD 6730M:
15.7  fps
83%
Radeon HD 6630M:
13 13 ~ 13 fps
108%
Radeon HD 6770M:
17  fps
The Witcher 2: Assassins of Kings

The Witcher 2: Assassins of Kings

2011
low 1024x768
Radeon HD 6630M:
23  fps
Crysis 2

Crysis 2

2011
low 800x600
100%
Radeon HD 6730M:
56.3  fps
91%
Radeon HD 6630M:
50.1 51.1 51.9 52.4 ~ 51 fps
149%
Radeon HD 6770M:
83.8  fps
med. 1024x768
100%
Radeon HD 6730M:
38.6  fps
85%
Radeon HD 6630M:
29.6 33.9 34 35 ~ 33 fps
147%
Radeon HD 6770M:
56.6  fps
high 1366x768
100%
Radeon HD 6730M:
28  fps
89%
Radeon HD 6630M:
23.2 24.8 25.5 26.1 ~ 25 fps
146%
Radeon HD 6770M:
40.8  fps
ultra 1920x1080
100%
Radeon HD 6730M:
11.6  fps
78%
Radeon HD 6630M:
8.9 8.9 ~ 9 fps
116%
Radeon HD 6770M:
13.4  fps
Total War: Shogun 2

Total War: Shogun 2

2011
low 1024x768
Radeon HD 6630M:
83.9 149 ~ 116 fps
med. 1280x720
Radeon HD 6630M:
24.3 25.2 ~ 25 fps
Radeon HD 6770M:
37.3  fps
ultra 1920x1080
Radeon HD 6630M:
9.1  fps
Radeon HD 6770M:
13.5  fps
Call of Duty: Black Ops

Call of Duty: Black Ops

2010
low 800x600
100%
Radeon HD 6730M:
110.3  fps
63%
Radeon HD 6630M:
59 78.7 ~ 69 fps
86%
Radeon HD 6770M:
95.2  fps
med. 1024x768
100%
Radeon HD 6730M:
69.9  fps
73%
Radeon HD 6630M:
47 51 55.9 ~ 51 fps
90%
Radeon HD 6770M:
58.8 67.2 ~ 63 fps
high 1360x768
100%
Radeon HD 6730M:
48.3  fps
83%
Radeon HD 6630M:
38 40.1 43 ~ 40 fps
112%
Radeon HD 6770M:
53.3 55.5 ~ 54 fps
ultra 1920x1080
100%
Radeon HD 6730M:
25.7  fps
86%
Radeon HD 6630M:
22  fps
125%
Radeon HD 6770M:
32  fps
Fifa 11

Fifa 11

2010
low 800x600
100%
Radeon HD 6730M:
345.4  fps
68%
Radeon HD 6630M:
228.3 238.7 ~ 234 fps
126%
Radeon HD 6770M:
264.1 456.6 458 566 ~ 436 fps
med. 1024x768
100%
Radeon HD 6730M:
245.1  fps
60%
Radeon HD 6630M:
134.5 158 ~ 146 fps
98%
Radeon HD 6770M:
192.4 251.7 256.2 258.3 ~ 240 fps
high 1360x768
100%
Radeon HD 6730M:
111  fps
82%
Radeon HD 6630M:
73.2 87 112.8 ~ 91 fps
114%
Radeon HD 6770M:
121.3 124.8 128.8 129.2 ~ 126 fps
ultra 1920x1080
100%
Radeon HD 6730M:
57.3  fps
99%
Radeon HD 6630M:
57  fps
112%
Radeon HD 6770M:
64.3  fps
Mafia 2

Mafia 2

2010
low 800x600
100%
Radeon HD 6730M:
69.1  fps
75%
Radeon HD 6630M:
49.6 54.5 ~ 52 fps
101%
Radeon HD 6770M:
63.7 71.2 75.3 ~ 70 fps
med. 1024x768
100%
Radeon HD 6730M:
55.1  fps
71%
Radeon HD 6630M:
37.3 39.1 40 ~ 39 fps
91%
Radeon HD 6770M:
47.4 50.1 52.7 ~ 50 fps
high 1360x768
100%
Radeon HD 6730M:
46.3  fps
69%
Radeon HD 6630M:
29.2 30.6 34.1 34.1 ~ 32 fps
86%
Radeon HD 6770M:
37.9 40 41.7 ~ 40 fps
ultra 1920x1080
100%
Radeon HD 6730M:
28.1  fps
73%
Radeon HD 6630M:
20.4  fps
100%
Radeon HD 6770M:
24.3 32 ~ 28 fps
StarCraft 2

StarCraft 2

2010
low 1024x768
100%
Radeon HD 6730M:
228.4  fps
60%
Radeon HD 6630M:
94 130.2 133.5 146 183 ~ 137 fps
73%
Radeon HD 6770M:
150.2 183.5 ~ 167 fps
med. 1360x768
100%
Radeon HD 6730M:
46.4  fps
101%
Radeon HD 6630M:
39 42.7 44.3 45.6 46 61.4 ~ 47 fps
140%
Radeon HD 6770M:
55.3 64.1 76.4 ~ 65 fps
high 1360x768
100%
Radeon HD 6730M:
28.6  fps
119%
Radeon HD 6630M:
27 28.7 29.7 30.4 40 47.8 ~ 34 fps
161%
Radeon HD 6770M:
39 44.6 55.1 ~ 46 fps
ultra 1920x1080
100%
Radeon HD 6730M:
18.2  fps
99%
Radeon HD 6630M:
17 19.2 ~ 18 fps
136%
Radeon HD 6770M:
24.7  fps
Just Cause 2

Just Cause 2

2010
ultra 1920x1080
Radeon HD 6630M:
9.2  fps
Radeon HD 6770M:
13.8  fps
Metro 2033

Metro 2033

2010
low 800x600
100%
Radeon HD 6730M:
66  fps
73%
Radeon HD 6630M:
47.4 48.2 ~ 48 fps
159%
Radeon HD 6770M:
76.1 89 123.9 131.7 ~ 105 fps
med. 1360x768
100%
Radeon HD 6730M:
31.7  fps
82%
Radeon HD 6630M:
25.4 26.4 ~ 26 fps
167%
Radeon HD 6770M:
40.1 45 63.7 63.8 ~ 53 fps
high 1600x900
100%
Radeon HD 6730M:
17  fps
135%
Radeon HD 6770M:
22.6 24 ~ 23 fps
ultra 1920x1080
100%
Radeon HD 6730M:
5.7  fps
140%
Radeon HD 6770M:
8 8.1 ~ 8 fps
Dawn of War II - Chaos Rising

Dawn of War II - Chaos Rising

2010
low 1024x768
Radeon HD 6630M:
71  fps
med. 1366x768
Radeon HD 6630M:
50  fps
high 1366x768
Radeon HD 6770M:
55.4  fps
ultra 1920x1080
Radeon HD 6770M:
26.5  fps
Battlefield: Bad Company 2

Battlefield: Bad Company 2

2010
low 1024x768
100%
Radeon HD 6730M:
67  fps
84%
Radeon HD 6630M:
52.2 52.4 62 ~ 56 fps
109%
Radeon HD 6770M:
72.7  fps
med. 1366x768
100%
Radeon HD 6730M:
51.1  fps
82%
Radeon HD 6630M:
39 40.7 40.9 47 ~ 42 fps
123%
Radeon HD 6770M:
57 69 ~ 63 fps
high 1366x768
100%
Radeon HD 6730M:
35  fps
86%
Radeon HD 6630M:
27.9 28.2 31.8 32 ~ 30 fps
126%
Radeon HD 6770M:
39.8 47.5 ~ 44 fps
ultra 1920x1080
100%
Radeon HD 6730M:
17.1  fps
82%
Radeon HD 6630M:
13.9 15 ~ 14 fps
125%
Radeon HD 6770M:
21.3  fps
Stalker: Call of Pripyat

Stalker: Call of Pripyat

2010
ultra 1920x1200
Radeon HD 6770M:
12  fps
CoD Modern Warfare 2

CoD Modern Warfare 2

2009
low 800x600
100%
Radeon HD 6730M:
137.2  fps
62%
Radeon HD 6630M:
84.6  fps
72%
Radeon HD 6770M:
98.3  fps
med. 1024x768
100%
Radeon HD 6730M:
51.2  fps
79%
Radeon HD 6630M:
40.3  fps
95%
Radeon HD 6770M:
48.7  fps
high 1366x768
100%
Radeon HD 6730M:
41.3  fps
79%
Radeon HD 6630M:
32.5  fps
97%
Radeon HD 6770M:
40  fps
ultra 1920x1080
100%
Radeon HD 6730M:
27  fps
98%
Radeon HD 6770M:
26.4  fps
Risen

Risen

2009
low 800x600
100%
Radeon HD 6730M:
75.5  fps
75%
Radeon HD 6630M:
51.6 63.1 ~ 57 fps
123%
Radeon HD 6770M:
71.6 90.8 103 105.2 ~ 93 fps
med. 1024x768
100%
Radeon HD 6730M:
43.9  fps
75%
Radeon HD 6630M:
26.6 31.3 36.2 37.5 ~ 33 fps
105%
Radeon HD 6770M:
42.3 43 44 45.7 53.3 ~ 46 fps
high 1366x768
100%
Radeon HD 6730M:
30.7  fps
75%
Radeon HD 6630M:
19.6 22.1 24.4 24.8 ~ 23 fps
101%
Radeon HD 6770M:
29.2 29.3 29.8 30.2 36.8 ~ 31 fps
ultra 1920x1080
100%
Radeon HD 6730M:
21.4  fps
82%
Radeon HD 6630M:
17.6  fps
100%
Radeon HD 6770M:
21.3  fps
Resident Evil 5

Resident Evil 5

2009
low 800x600
100%
Radeon HD 6730M:
119.9  fps
78%
Radeon HD 6630M:
88.1 99.4 ~ 94 fps
80%
Radeon HD 6770M:
96.2  fps
high 1360x768
100%
Radeon HD 6730M:
54.1  fps
79%
Radeon HD 6630M:
42.4 42.8 ~ 43 fps
112%
Radeon HD 6770M:
60.8  fps
ultra 1920x1080
100%
Radeon HD 6730M:
29.8  fps
82%
Radeon HD 6630M:
24.4  fps
124%
Radeon HD 6770M:
35.5 39 ~ 37 fps
Need for Speed Shift

Need for Speed Shift

2009
low 800x600
Radeon HD 6770M:
74.1 82.5 ~ 78 fps
med. 1024x768
100%
Radeon HD 6730M:
54  fps
65%
Radeon HD 6630M:
27.6 32.9 44.6 ~ 35 fps
85%
Radeon HD 6770M:
38.1 46.7 47.7 51.9 ~ 46 fps
high 1366x768
100%
Radeon HD 6730M:
35.7  fps
78%
Radeon HD 6630M:
21.7 30 33.5 ~ 28 fps
118%
Radeon HD 6770M:
39.7 39.9 42.8 44.2 ~ 42 fps
ultra 1920x1080
100%
Radeon HD 6730M:
22.1  fps
127%
Radeon HD 6770M:
28  fps
Colin McRae: DIRT 2

Colin McRae: DIRT 2

2009
low 800x600
Radeon HD 6630M:
60.5 80 ~ 70 fps
Radeon HD 6770M:
81 88 91.5 ~ 87 fps
med. 1024x768
Radeon HD 6630M:
52.2 57.2 ~ 55 fps
Radeon HD 6770M:
66 73.6 74.7 ~ 71 fps
high 1360x768
Radeon HD 6630M:
28.2 33.4 ~ 31 fps
Radeon HD 6770M:
45.1 49.3 50.5 ~ 48 fps
Anno 1404

Anno 1404

2009
low 1024x768
Radeon HD 6630M:
136.7  fps
ultra 1280x1024
Radeon HD 6630M:
30.6  fps
Sims 3

Sims 3

2009
high 1280x1024
Radeon HD 6630M:
42  fps
Far Cry 2

Far Cry 2

2008
low 640x480
Radeon HD 6630M:
101 131.1 ~ 116 fps
high 1024x768
Radeon HD 6630M:
46 51.2 ~ 49 fps
ultra 1920x1080
Radeon HD 6630M:
16.7  fps
Racedriver: GRID

Racedriver: GRID

2008
low 800x600
Radeon HD 6770M:
122.7  fps
med. 1024x768
Radeon HD 6770M:
81.2  fps
high 1280x1024
Radeon HD 6770M:
51.6  fps
Trackmania Nations Forever

Trackmania Nations Forever

2008
low 640x480
Radeon HD 6630M:
173  fps
high 1024x768
Radeon HD 6630M:
50.3  fps
ultra 1920x1080
Radeon HD 6630M:
21.4  fps
Radeon HD 6770M:
35.8  fps
Call of Duty 4 - Modern Warfare

Call of Duty 4 - Modern Warfare

2007
low 800x600
Radeon HD 6770M:
226.6 228.1 287.7 ~ 247 fps
med. 1024x768
Radeon HD 6770M:
135.7 146.8 161.6 ~ 148 fps
high 1280x1024
Radeon HD 6770M:
79.3  fps
Supreme Commander - FA Bench

Supreme Commander - FA Bench

2007
low 1024x768
Radeon HD 6630M:
51.9  fps
Radeon HD 6770M:
56.6  fps
med. 1024x768
Radeon HD 6630M:
43.3  fps
Radeon HD 6770M:
48.1  fps
high 1024x768
Radeon HD 6630M:
34.6  fps
Radeon HD 6770M:
44  fps
ultra 1920x1080
Radeon HD 6630M:
16.8  fps
Radeon HD 6770M:
27  fps
Crysis - GPU Benchmark

Crysis - GPU Benchmark

2007
med. 1024x768
Radeon HD 6630M:
41.3  fps
high 1024x768
Radeon HD 6630M:
28.7 30.6 ~ 30 fps
Radeon HD 6770M:
43.8  fps
ultra 1920x1080
Radeon HD 6630M:
7.8 8.1 ~ 8 fps
Radeon HD 6770M:
11.9  fps
Crysis - CPU Benchmark

Crysis - CPU Benchmark

2007
med. 1024x768
Radeon HD 6630M:
38.9  fps
high 1024x768
Radeon HD 6630M:
24.2 25.7 ~ 25 fps
Radeon HD 6770M:
36.4  fps
ultra 1920x1080
Radeon HD 6630M:
7.2 7.5 ~ 7 fps
World in Conflict - Benchmark

World in Conflict - Benchmark

2007
low 800x600
Radeon HD 6630M:
112  fps
med. 1024x768
Radeon HD 6630M:
50  fps
high 1024x768
Radeon HD 6630M:
34  fps
Radeon HD 6770M:
56  fps
ultra 1920x1080
Radeon HD 6630M:
12  fps
Radeon HD 6770M:
20  fps
Call of Juarez Benchmark

Call of Juarez Benchmark

2006
high 1024x768
Radeon HD 6770M:
40.4 43.9 44.1 ~ 43 fps
World of Warcraft

World of Warcraft

2005
low 800x600
Radeon HD 6630M:
160.7  fps
med. 1024x768
Radeon HD 6630M:
132  fps
high 1280x1024
Radeon HD 6630M:
43.4  fps

Average Gaming AMD Radeon HD 6730M → 100%

Average Gaming 30-70 fps → 100%

Average Gaming AMD Radeon HD 6630M → 80%

Average Gaming 30-70 fps → 83%

Average Gaming AMD Radeon HD 6770M → 113%

Average Gaming 30-70 fps → 116%

AMD Radeon HD 6730MAMD Radeon HD 6630MAMD Radeon HD 6770M
lowmed.highultraQHD4Klowmed.highultraQHD4Klowmed.highultraQHD4K
Risen 2: Dark Waters3321168
Mass Effect 3433818
Anno 207074281810100412714
The Elder Scrolls V: Skyrim5032201059413015
CoD: Modern Warfare 3155643820
Battlefield 3342220382722
Fifa 126635297.1150.893.752
F1 201159372013105673619
Deus Ex Human Revolution8033141254219
Dirt 3134.862.941.615.79867381383.25446.317
The Witcher 2: Assassins of Kings23
Crysis 256.338.62811.6513325983.856.640.813.4
Total War: Shogun 2116259.137.313.5
Call of Duty: Black Ops110.369.948.325.76951402295.2635432
Fifa 11345.4245.111157.3234146915743624012664.3
Mafia 269.155.146.328.152393220.470504028
StarCraft 2228.446.428.618.2137473418167654624.7
Just Cause 29.1513.8
Metro 20336631.7175.7482610553238
Dawn of War II - Chaos Rising715055.426.5
Battlefield: Bad Company 26751.13517.15642301472.7634421.3
CoD Modern Warfare 2137.251.241.32784.640.332.598.348.74026.4
Risen75.543.930.721.457332317.693463121.3
Resident Evil 5119.954.129.8944324.496.260.837
Need for Speed Shift5435.722.1352878464228
Colin McRae: DIRT 2705531877148
Anno 1404136.730.6
Sims 342
Far Cry 21164916.7
Trackmania Nations Forever17350.321.435.8
Supreme Commander - FA Bench51.943.334.616.856.648.14427
Crysis - GPU Benchmark41.330843.811.9
Crysis - CPU Benchmark38.925736.4
World in Conflict - Benchmark1125034125620
World of Warcraft160.713243.4
AMD Radeon HD 6730MAMD Radeon HD 6630MAMD Radeon HD 6770M
lowmed.highultraQHD4Klowmed.highultraQHD4Klowmed.highultraQHD4K
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps
1
6
4
8
2
1		3
8
1
11
1







< 30 fps
< 60 fps
< 120 fps
≥ 120 fps		1
11
11
6		5
16
2
2		9
18
2
23
3







< 30 fps
< 60 fps
< 120 fps
≥ 120 fps
3
13
4		1
11
5
2		3
18
2
1		19
4
1






For more games that might be playable and a list of all games and graphics cards visit our Gaming List

v1.33
log 06. 23:45:26

#0 ran 0s before starting gpusingle class +0s ... 0s

#1 checking url part for id 2090 +0s ... 0s

#2 checking url part for id 2094 +0s ... 0s

#3 checking url part for id 2086 +0s ... 0s

#4 not redirecting to Ajax server +0s ... 0s

#5 did not recreate cache, as it is less than 5 days old! Created at Wed, 04 Jun 2025 05:19:53 +0200 +0s ... 0s

#6 composed specs +0.023s ... 0.024s

#7 did output specs +0s ... 0.024s

#8 start showIntegratedCPUs +0s ... 0.024s

#9 getting avg benchmarks for device 2090 +0.021s ... 0.045s

#10 got single benchmarks 2090 +0.004s ... 0.049s

#11 getting avg benchmarks for device 2094 +0s ... 0.049s

#12 got single benchmarks 2094 +0.018s ... 0.067s

#13 getting avg benchmarks for device 2086 +0s ... 0.068s

#14 got single benchmarks 2086 +0.011s ... 0.079s

#15 got avg benchmarks for devices +0s ... 0.079s

#16 min, max, avg, median took s +0.022s ... 0.101s

#17 before gaming benchmark output +0s ... 0.101s

#18 Got 426 rows for game benchmarks. +0.016s ... 0.117s

#19 composed SQL query for gamebenchmarks +0s ... 0.117s

#20 got data and put it in $dataArray +0.004s ... 0.121s

#21 benchmarks composed for output. +0.016s ... 0.137s

#22 calculated avg scores. +0s ... 0.137s

#23 return log +0.001s ... 0.138s

Please share our article, every link counts!
Mail Logo
> Expert Reviews and News on Laptops, Smartphones and Tech Innovations > Benchmarks / Tech > Graphics Card Comparison - Head 2 Head
Redaktion, 2017-09- 8 (Update: 2023-07- 1)
