AMD Ryzen 5 7535HS vs AMD Ryzen 5 7535U vs AMD Ryzen Z2 Go

AMD Ryzen 5 7535HS

The AMD Ryzen 5 7535HS is a processor for big (gaming) laptops based of the Rembrandt Refresh generation. The R5 7535HS integrates six of the eight cores based on the Zen 3+ microarchitecture. They are clocked at 3.3 (guaranteed base clock) to 4.55 GHz (boost) and support SMT / Hyperthreading (12 threads). The 7535HS is a refresh of the old Ryzen 5 6600HS / 6600H with 50 MHz higher boost clock speed.

The Zen 3+ architecture is a refresh of Zen 3 and should not offer a lot of changes. The chip itself however, offers some modern features, like support for USB 4 (40 Gbps), PCI-E Gen 4 and DDR5-4800MT/s or LPDDR5-6400MT/s.

The processor performance is very similar to the Ryzen 5 6600HS (35 Watt TDP) or Ryzen 5 6600H (55 Watt TDP) due to the similar specs.

In the 6000 series, AMD switched to the RDNA 2 graphics architecture for the iGPU. As the 6600HS the 7535HS only offers the slower Radeon 660M with 6 of the 12 CUs enabled and 1.9 GHz max. clock rate.

The TDP of the APU is specified from 35 to 54 Watt. The monolithic chip is manufactured in 6nm at TSMC.

AMD Ryzen 5 7535U

The AMD Ryzen 5 7535U is a processor for thin and light laptops based of the Rembrandt refresh generation. The Ryzen packs six of the eight cores based on the Zen 3+ microarchitecture. They are clocked at 2.9 (guaranteed base clock) to 4.55 GHz (Turbo) and support SMT / Hyperthreading (12 threads). The chip is manufactured in 6 nm FinFET at TSMC. The 7535U is the refresh of the 2022 AMD Ryzen 5 6600U and offers 50 MHz higher boost clock at a 3W higher maximum TDP.

The Zen 3+ is a refresh of the Zen 3 architecture and should not offer a lot of changes. The chip offers modern features, like support for USB 4 (40 Gbps), PCI-E Gen 4 and DDR5-4800MT/s or LPDDR5-6400MT/s.

The performance should be quite similar to the old Ryzen 5 6600U due to only a slightly increased boost speed (+50MHz) and TDP (28 versus 15-25W).

The integrated GPU Radeon 660M is still a fast iGPUs based on the RDNA2 architecture and offers 6 of the 12 CUs at up to 1.9 GHz.

The Ryzen 7535U is manufactured in 6nm FinFET at TSMC and specified at a TDP of 28W.

AMD Ryzen Z2 Go

The AMD Ryzen Z2 Go is a processor for cheap handhelds based of the Rembrandt refresh generation. The Ryzen packs four of the eight cores based on the Zen 3+ microarchitecture. They are clocked at 3 (guaranteed base clock) to 4.3 GHz (single core boost) and support SMT / Hyperthreading (8 threads). The Ryzen Z2 Go is based on the same chip as the old AMD Ryzen 7335U, but with a faster iGPU with all 12 CUs (Radeon 680M, clock speed not currently known).

The Zen 3+ is a refresh of the Zen 3 architecture and should not offer a lot of changes. The chip offers modern features, like support for USB 4 (40 Gbps), PCI-E Gen 4 and DDR5-4800MT/s or LPDDR5-6400MT/s.

The performance should be clearly better than the old Ryzen 3 5300U and Ryzen 3 5425U due to the higher clock speed and improved architecture. The similar named other Ryzen Z2 chips, are based on newer chips and therefore clearly faster and more energy efficient.

The Ryzen Z2 Go is manufactured in 6nm FinFET at TSMC and specified at a TDP of 28W (15 - 30 Watt configurable).
