ATI Mobility Radeon 9000 vs ATI Mobility Radeon 9200
ATI Mobility Radeon 9000
► remove from comparison
The AMD / ATI Mobility Radeon 9000 was the first DirectX 8.1 capable graphic card for laptops and offered a good gaming performance at the date of the market introduction in 2002. The speed can be compared with the desktop version, which is similarly clocked. The ATI Mobility Radeon 9000 was the competitor to the GeForce 4 Go 460 and similar fast. Older games like Max Payne run sufficiently fast with this chip (more than 35 images by second). At moment, the performance can only be compared with integrated graphic cards (like GMA 950).
At moment, there are no Windows Vista Aero drivers available for the ATI Mobility Radeon 9000.
ATI Mobility Radeon 9200
► remove from comparison
The ATI Mobility 9200 is a higher clocked ATI Mobility Radeon 9000. The difference is only the higher chip clock (250 MHz, compared to 240 MHz) and the support for 8x AGP (compared to 4x AGP).
The DirectX 8.1 capable graphic card for laptops presented good performance data at the date of introduction. The speed can be compared with the desktop version, which is clocked similarly. The ATI Mobility Radeon 9200 was the competitor of the GeForce 4 Go 460, which was sometimes faster and slower. Older games like Max Payne run sufficiently fast with this chip (more than 35 images per second). At moment, the performance can only be compared with integrated graphic cards (like GMA 950).
At moment, no Windows Vista Aero drivers are available for the ATI Mobility Radeon 9200.
| ATI Mobility Radeon 9000 | ATI Mobility Radeon 9200 | |||||||||||||
| Mobility Radeon 9000 Series |
|
| ||||||||||||
| Codename | M9 | M9 | ||||||||||||
| Pipelines | 4 / 1 Pixel- / Vertexshader | 4 / 1 Pixel- / Vertexshader | ||||||||||||
| Core Speed | 240 MHz | 250 MHz | ||||||||||||
| Memory Speed | 200 MHz | 200 MHz | ||||||||||||
| Memory Bus Width | 128 Bit | 128 Bit | ||||||||||||
| Memory Type | DDR | DDR | ||||||||||||
| Max. Amount of Memory | 128 MB | 64 MB | ||||||||||||
| Shared Memory | no | no | ||||||||||||
| API | DirectX 8.1, Shader 1.4 | DirectX 8.1, Shader 1.4 | ||||||||||||
| Transistors | 30 Million | 30 Million | ||||||||||||
| technology | 150 nm | 150 nm | ||||||||||||
| Features | AGP 4x, 150nm processing technology, 952 MPixel/s pixel-filling rate, theoretical filling rate: 9601000 Mpixel/s, memory bandwidth: 64007040 MB/s, Hyper-Z II optimization for memory bandwidth, Smoothvision: Super Sampling FSAA, Powerplay (not activated in all laptops!), integrated MPEG2 decoder-units like iDCT, Motion Compensation, hardware sub-picture-decoder, adaptive de-interlacing, 400 MHz RAMDAC, 165 MHz TMDS-transmitter, integrated video-exit, support for several display devices by ATi Hydravision (up to 3 displays simultaneously). | AGP 8x, 150nm processing technology, 952 MPixel/s pixel-filling rate, theoretical filling rate: 9601000 Mpixel/s, memory bandwidth: 64007040 MB/s, Hyper-Z II optimization for memory bandwidth, Smoothvision: Super Sampling FSAA, Powerplay (not activated in all laptops!), integrated MPEG2 decoder-units like iDCT, Motion Compensation, hardware sub-picture-decoder, adaptive de-interlacing, 400 MHz RAMDAC, 165 MHz TMDS-transmitter, integrated video-exit, support for several display devices by ATi Hydravision (up to 3 displays simultaneously). | ||||||||||||
| Date of Announcement | 01.09.2002 | 01.03.2003 |
Benchmarks
Average Benchmarks ATI Mobility Radeon 9000 → 100% n=2
Average Benchmarks ATI Mobility Radeon 9200 → 143% n=2
- Average benchmark values for this graphics card* Smaller numbers mean a higher performance
1 This benchmark is not used for the average calculation
For more games that might be playable and a list of all games and graphics cards visit our Gaming List
