ARM Immortalis-G720 MP7 vs ARM Immortalis-G720 MP12

ARM Immortalis-G720 MP7

► remove from comparison ARM Immortalis-G720 MP7

The ARM Immortalis-G720 MP7 (or MC7) is a mid-range GPU for smartphones and tablets, which can be found in this form for the first time in the MediaTek Dimensity 8400.

It uses 7 of the 16 possible cores and is based on the latest 5th generation GPU architecture. According to ARM, it offers 15 percent higher performance than the previous generation with the same number of cores and can access 40 percent more memory bandwidth.

In our test of the Dimensity 8400 in the Xiaomi Poco X7 Pro, the GPU performed at around the same level as an Adreno 735 in the Snapdragon 8s Gen 3.

The Immortalis-G720 GPUs support Variable Rate Shading (VRS), Deferred Vertex Shading (DVS) and hardware-based ray tracing. The GPU is manufactured in 4 nanometers.

ARM Immortalis-G720 MP12

► remove from comparison ARM Immortalis-G720 MP12

The ARM Immortalis-G720 MP12 (MC12) is a high-end GPU for smartphones and tablets, which was used for the first time in this form in the MediaTek Dimensity 9300 in this form.

It uses 12 of the 16 possible cores and is based on the latest 5th generation GPU architecture (successor to valhall). According to ARM, it offers 15 percent higher performance than the previous generation with the same number of cores and can access 40 percent more memory bandwidth.

In our test of the Dimensity 9300 in the Vivo X100 Pro, the GPU can outperform the older Immortalis-G715 MP11 but remains behind an Adreno 750.

The Immortalis-G720 GPUs support Variable Rate Shading (VRS), Deferred Vertex Shading (DVS) and hardware-based ray tracing. The GPU is manufactured in 4 nanometers.

show full text
ARM Immortalis-G720 MP7ARM Immortalis-G720 MP12
Immortalis-G720 Series
Immortalis-G720 MP12 12
Immortalis-G720 MP7 7
Immortalis-G720 MP12 12
Immortalis-G720 MP7 7
CodenameKrakeKrake
Architecture5th Gen5th Gen
Pipelines7 - unified12 - unified
Shared Memoryyesyes
APIOpenGL ES 3.2, OpenCL 3.0, Vulkan 1.3OpenGL ES 3.2, OpenCL 3.0, Vulkan 1.3
technology4 nm4 nm
FeaturesOpenGL ES 3.2, OpenCL 2.0 FP, Vulkan 1.2, ASTC, AFBCOpenGL ES 3.2, OpenCL 2.0 FP, Vulkan 1.2, ASTC, AFBC
Date of Announcement29.05.2023 29.05.2023
Link to Manufacturer Pagewww.arm.comwww.arm.com
CPU in Immortalis-G720 MP7GPU Base SpeedGPU Boost / Turbo
MediaTek Dimensity 84008 x 2100 MHz? MHz? MHz
CPU in Immortalis-G720 MP12GPU Base SpeedGPU Boost / Turbo
Mediatek Dimensity 9400e8 x 2000 MHz? MHz? MHz

Benchmarks

3DMark - 3DMark Sling Shot (ES 3.0) Unlimited
18733 Points (81%)
3DMark - 3DMark Sling Shot (ES 3.0) Unlimited Graphics
27796 Points (61%)
3DMark - 3DMark Sling Shot Extreme (ES 3.1) Unlimited
14161 Points (60%)
min: 15904     avg: 16854     median: 16919.5 (71%)     max: 17674 Points
3DMark - 3DMark Sling Shot Extreme (ES 3.1) Unlimited Graphics
20018 Points (50%)
min: 22189     avg: 25517     median: 25277 (63%)     max: 29325 Points
3DMark - 3DMark Wild Life Unlimited
12261 Points (6%)
min: 13588     avg: 17328     median: 18352 (9%)     max: 18628 Points
3DMark - 3DMark Wild Life Extreme Unlimited
3691 Points (4%)
min: 3866     avg: 5079     median: 5289 (6%)     max: 5527 Points
GFXBench - GFXBench 5.0 4K Aztec Ruins High Tier Offscreen
28 fps (10%)
min: 33     avg: 37.4     median: 35 (13%)     max: 43 fps
GFXBench - GFXBench 5.0 Aztec Ruins High Tier Offscreen
61 fps (11%)
min: 72     avg: 82.6     median: 83 (15%)     max: 94 fps
GFXBench - GFXBench 5.0 Aztec Ruins Normal Tier Offscreen
153 fps (11%)
min: 176     avg: 201.2     median: 198 (15%)     max: 236 fps
GFXBench - GFXBench Car Chase Offscreen
122 fps (12%)
min: 135     avg: 144.4     median: 144 (14%)     max: 153 fps
GFXBench 3.1 - GFXBench Manhattan ES 3.1 Offscreen
199 fps (4%)
min: 201     avg: 234.2     median: 231 (5%)     max: 269 fps
GFXBench 3.0 - GFXBench 3.0 Manhattan Offscreen
243 fps (10%)
min: 221     avg: 299.4     median: 261 (11%)     max: 478 fps
GFXBench (DX / GLBenchmark) 2.7
GFXBench T-Rex HD Offscreen C24Z16 + ARM Immortalis-G720 MP7
GFXBench (DX / GLBenchmark) 2.7 - GFXBench T-Rex HD Offscreen C24Z16
568 fps (5%)
GFXBench T-Rex HD Offscreen C24Z16 + ARM Immortalis-G720 MP12
min: 738     avg: 787     median: 791 (6%)     max: 831 fps
Antutu v9 - AnTuTu v9 GPU
524874 Points (52%)
644667 Points (64%)
Antutu v10 - AnTuTu v10 GPU
618749 Points (49%)
min: 672407     avg: 814428     median: 841482 (67%)     max: 866486 Points
Basemark GPU 1.2 - Basemark GPU 1.2 Vulkan Official Medium Offscreen 1080
144.2 fps (4%)
min: 178.3     avg: 217.8     median: 229 (6%)     max: 246.01 fps
Geekbench 6.4 - Geekbench 6.4 GPU OpenCL
12429 Points (3%)
min: 12163     avg: 13755     median: 14675 (4%)     max: 15025 Points
Geekbench 6.4 - Geekbench 6.4 GPU Vulkan
12913 Points (3%)
min: 13826     avg: 15108     median: 15598 (4%)     max: 15920 Points
Power Consumption - GFXBench Aztec Ruins Normal Tier Offscreen Power Consumption 150cd *
13.8 Watt (5%)
min: 11.7     avg: 13.8     median: 13.8 (5%)     max: 15.9 Watt

Average Benchmarks ARM Immortalis-G720 MP7 → 100% n=16

Average Benchmarks ARM Immortalis-G720 MP12 → 129% n=16

- Range of benchmark values for this graphics card
red legend - Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
1 This benchmark is not used for the average calculation

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

Genshin Impact

Genshin Impact

2020
low
100%
Immortalis-G720 MP7:
59.7  fps
101%
Immortalis-G720 MP12:
59.9 60 60 60 ~ 60 fps
med.
Immortalis-G720 MP12:
59  fps
ultra
100%
Immortalis-G720 MP7:
59.5  fps
97%
Immortalis-G720 MP12:
56 58 59 59.9 ~ 58 fps
PUBG Mobile

PUBG Mobile

2018
low
100%
Immortalis-G720 MP7:
117.8  fps
92%
Immortalis-G720 MP12:
90 111.9 112 119 ~ 108 fps
high
100%
Immortalis-G720 MP7:
59.7  fps
92%
Immortalis-G720 MP12:
40 59.6 60 60 ~ 55 fps
ultra
Immortalis-G720 MP12:
39.8 40 40 ~ 40 fps
Dead Trigger 2

Dead Trigger 2

2013
high
Immortalis-G720 MP12:
60 71 ~ 66 fps
Asphalt 9: Legends

Asphalt 9: Legends

2013
low
100%
Immortalis-G720 MP7:
59.9  fps
high
100%
Immortalis-G720 MP7:
59.6  fps
98%
Immortalis-G720 MP12:
58.3  fps

Average Gaming ARM Immortalis-G720 MP7 → 100%

Average Gaming 30-70 fps → 100%

Average Gaming ARM Immortalis-G720 MP12 → 96%

Average Gaming 30-70 fps → 97%

ARM Immortalis-G720 MP7ARM Immortalis-G720 MP12
lowmed.highultraQHD4Klowmed.highultraQHD4K
Genshin Impact59.759.5605958
PUBG Mobile117.859.71085540
Asphalt 9: Legends59.959.658.3
ARM Immortalis-G720 MP7ARM Immortalis-G720 MP12
lowmed.highultraQHD4Klowmed.highultraQHD4K
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps
2
1




2


1







< 30 fps
< 60 fps
< 120 fps
≥ 120 fps

2

1


2


2







For more games that might be playable and a list of all games and graphics cards visit our Gaming List
